C70QPL100M4CAD

Three-phase 3 and 4-wire MID meter, 400V-100A direct, Modbus RTU

MID-certified electric energy meter for three-phase 3 and 4-wire networks. Direct connection up to 100 A. Bidirectional, active energy accuracy class B (EN 50470-3), multi-measurement. Two S0 pulse outputs and RS485 Modbus RTU communication. Extended operating temperature range up to 70 °C. 4-DIN-module enclosure.

Data sheet
